Lifting capacity at full reach, 240 Bar, w/o grapple and rotator, kg
650
Lifting capacity at full reach, 215 Bar, w/o grapple and rotator, kg
530
Lifting capacity at full reach, 195 Bar, w/o grapple and rotator, kg
450
Lifting capacity at 4 m, 240 Bar, w/o grapple and rotator, kg
1750
Lifting capacity at 4m, 215 Bar, w/o grapple and rotator, kg
1510
Lifting capacity at 4m, 195 Bar, w/o grapple and rotator, kg
1360
Brutto lifting torque 240 Bar, kNm
96
Brutto lifting torque 215 Bar, kNm
86
Brutto lifting torque 195 bar, kNm
78
Telescopic boom stroke length, m
3,8
Slewing cylinder amount in slewing housing, pcs
4
Working pressure, bar
195/215/240
Rotator maximum load, kN
60
Crane weight without support leg and valve block, kg
1310
Pillar slewing angle, degrees
380
Recommended oil flow, L/min
60-120
