Series |
5 |
Max outreach, m |
8,7 |
Lifting capacity at full reach, 215 Bar, w/o grapple and rotator, kg |
490 (8.4 m) |
Lifting capacity at 4m, 215 Bar, w/o grapple and rotator, kg |
1235 |
Brutto lifting torque 215 Bar, kNm |
63 |
Telescopic boom stroke length, m |
3,3 |
Slewing cylinder amount in slewing housing, pcs |
4 |
Slewing torque, kNm |
17 |
Working pressure, bar |
215 |
Rotator maximum load, kN |
60 |
Crane weight without support leg and valve block, kg |
995 |
Pillar slewing angle, degrees |
340 |
Recommended oil flow, L/min |
50-90 |
